Use GPT, Claude, and Gemini Models Inside Claude Code on Windows with CLIProxyAPI

CLIProxyAPI can run as a local compatibility gateway between Claude Code and several OAuth-backed model providers. With one local server, you can keep Claude Code's terminal workflow while switching between:

• GPT models authenticated through OpenAI Codex OAuth
• Claude models exposed through Antigravity OAuth
• Gemini models exposed through Antigravity OAuth
• Separate reusable Claude Code profiles for each provider setup

This guide documents the complete Windows setup, including the mistakes that are easiest to make and the exact commands needed to recover from them.

Important compatibility note: CLIProxyAPI is a third-party gateway. Claude Code supports custom gateway URLs, model aliases, environment-variable configuration, and separate configuration directories. Routing Claude Code to models that are not served directly by Anthropic remains an unofficial compatibility workflow. Test tool use, streaming, thinking blocks, prompt caching, MCP integrations, and long-running agents after upgrades.

1. What this setup creates

The local request path is:

Claude Code
    │
    │ Anthropic-compatible request
    ▼
CLIProxyAPI
http://127.0.0.1:8317
    │
    ├── Codex OAuth
    │      └── GPT models
    │
    └── Antigravity OAuth
           ├── Claude models
           └── Gemini models

The final Windows commands will be:

cliproxy
cliproxy-ui
cliproxy-stop
claude-gpt
claude-antigravity

Their jobs are:

The two Claude Code profiles remain separate:

%USERPROFILE%\.claude-gpt
%USERPROFILE%\.claude-antigravity

Claude Code officially supports relocating its entire configuration directory with CLAUDE_CONFIG_DIR. That makes it useful for separate settings, histories, plugins, credentials, and sessions.

2. Requirements

You need:

• Windows 10 or Windows 11
• Windows PowerShell 5.1 or PowerShell 7
• Internet access
• Claude Code
• A ChatGPT account that can authenticate with Codex
• A Google account that can authenticate with Antigravity
• The latest Windows AMD64 build of CLIProxyAPI

This guide installs CLIProxyAPI under:

C:\Users\<YOUR_WINDOWS_USERNAME>\CLIProxyAPI

The local endpoints are:

Proxy base URL:
http://127.0.0.1:8317

OpenAI-compatible API:
http://127.0.0.1:8317/v1

Claude-compatible messages endpoint:
http://127.0.0.1:8317/v1/messages

Model list:
http://127.0.0.1:8317/v1/models

Management UI:
http://127.0.0.1:8317/management.html

3. Install Claude Code

Recommended native PowerShell installer

Run:

irm https://claude.ai/install.ps1 | iex

Verify:

claude --version
claude doctor

WinGet alternative

winget install Anthropic.ClaudeCode

Update a WinGet installation with:

winget upgrade Anthropic.ClaudeCode

Check where Windows found Claude Code:

Get-Command claude |
    Select-Object Name, Source

From Command Prompt:

where claude

If the installer completed but claude is not recognized, open a new terminal and check whether this location exists:

Test-Path "$env:USERPROFILE\.local\bin\claude.exe"

4. Install CLIProxyAPI automatically

The following PowerShell installer:

1. Finds the latest CLIProxyAPI release.
2. Downloads the Windows AMD64 archive.
3. Extracts the release into your user profile.
4. Preserves an existing config.yaml during upgrades.
5. Creates a secure local configuration on a fresh installation.
6. Generates separate client and management credentials.
7. Restricts the server to localhost.
8. Adds the installation folder to the user PATH.
9. Creates cliproxy, cliproxy-ui, and cliproxy-stop.
10. Makes the commands available in the current terminal.

Open PowerShell and paste the entire block:

$ErrorActionPreference = "Stop"

$repo = "router-for-me/CLIProxyAPI"
$installDir = Join-Path $env:USERPROFILE "CLIProxyAPI"
$downloadPath = Join-Path $env:TEMP "CLIProxyAPI-latest.zip"
$extractDir = Join-Path $env:TEMP "CLIProxyAPI-extracted"

Write-Host "Installing CLIProxyAPI into $installDir"

# Find the newest GitHub release.
$release = Invoke-RestMethod `
    -Uri "https://api.github.com/repos/$repo/releases/latest" `
    -Headers @{
        "User-Agent" = "CLIProxyAPI-Windows-Installer"
    }

# Find the 64-bit Windows ZIP.
$asset = $release.assets |
    Where-Object {
        $_.name -match "windows_amd64\.zip$"
    } |
    Select-Object -First 1

if (-not $asset) {
    throw "The latest release does not contain a Windows AMD64 ZIP."
}

# Download it.
Invoke-WebRequest `
    -Uri $asset.browser_download_url `
    -OutFile $downloadPath

# Prepare temporary extraction.
Remove-Item `
    -Path $extractDir `
    -Recurse `
    -Force `
    -ErrorAction SilentlyContinue

New-Item `
    -ItemType Directory `
    -Path $extractDir `
    -Force |
    Out-Null

New-Item `
    -ItemType Directory `
    -Path $installDir `
    -Force |
    Out-Null

Expand-Archive `
    -Path $downloadPath `
    -DestinationPath $extractDir `
    -Force

# Locate the actual release directory.
$exe = Get-ChildItem `
    -Path $extractDir `
    -Filter "cli-proxy-api.exe" `
    -Recurse |
    Select-Object -First 1

if (-not $exe) {
    throw "cli-proxy-api.exe was not found in the release archive."
}

$releaseFolder = Split-Path $exe.FullName -Parent

# Preserve an existing configuration during upgrades.
$configPath = Join-Path $installDir "config.yaml"
$hadExistingConfig = Test-Path $configPath
$configBackup = $null

if ($hadExistingConfig) {
    $configBackup = Join-Path `
        $env:TEMP `
        "CLIProxyAPI-config-preserved.yaml"

    Copy-Item `
        -Path $configPath `
        -Destination $configBackup `
        -Force
}

# Copy the newest release files.
Get-ChildItem `
    -Path $releaseFolder `
    -Force |
    Copy-Item `
        -Destination $installDir `
        -Recurse `
        -Force

# Restore the existing config, or create one from the example.
if ($configBackup -and (Test-Path $configBackup)) {
    Copy-Item `
        -Path $configBackup `
        -Destination $configPath `
        -Force
}
elseif (-not (Test-Path $configPath)) {
    $exampleConfig = Join-Path `
        $installDir `
        "config.example.yaml"

    if (-not (Test-Path $exampleConfig)) {
        throw "config.example.yaml was not found."
    }

    Copy-Item `
        -Path $exampleConfig `
        -Destination $configPath `
        -Force
}

$generatedSecrets = $false

# Create a secure local configuration on a fresh installation.
if (-not $hadExistingConfig) {
    function New-UrlSafeSecret {
        param(
            [Parameter(Mandatory)]
            [string]$Prefix,

            [int]$ByteLength = 32
        )

        $bytes = New-Object byte[] $ByteLength
        $rng = [Security.Cryptography.RandomNumberGenerator]::Create()

        try {
            $rng.GetBytes($bytes)
        }
        finally {
            $rng.Dispose()
        }

        $encoded = [Convert]::ToBase64String($bytes)
        $encoded = $encoded.TrimEnd("=")
        $encoded = $encoded.Replace("+", "-")
        $encoded = $encoded.Replace("/", "_")

        return "$Prefix$encoded"
    }

    $clientKey = New-UrlSafeSecret `
        -Prefix "cc-local-" `
        -ByteLength 32

    $managementKey = New-UrlSafeSecret `
        -Prefix "mgt-local-" `
        -ByteLength 36

    $configText = Get-Content `
        -Path $configPath `
        -Raw

    $hostPattern = [regex]'(?m)^host:\s*""\s*$'

    $managementPattern = [regex](
        '(?m)^\s{2}secret-key:\s*""\s*$'
    )

    $apiKeysPattern = [regex](
        '(?ms)^api-keys:\s*\r?\n' +
        '(?:\s{2}-\s*"your-api-key-\d+"\s*\r?\n?)+'
    )

    $configText = $hostPattern.Replace(
        $configText,
        'host: "127.0.0.1"',
        1
    )

    $configText = $managementPattern.Replace(
        $configText,
        '  secret-key: "' + $managementKey + '"',
        1
    )

    $apiKeyReplacement = (
        "api-keys:`r`n" +
        '  - "' + $clientKey + '"' +
        "`r`n"
    )

    $configText = $apiKeysPattern.Replace(
        $configText,
        $apiKeyReplacement,
        1
    )

    Set-Content `
        -Path $configPath `
        -Value $configText `
        -Encoding UTF8

    $generatedSecrets = $true
}

Unblock-File `
    -Path (Join-Path $installDir "cli-proxy-api.exe")

# Add the installation directory to the current PATH.
if (($env:Path -split ";") -notcontains $installDir) {
    $env:Path = "$env:Path;$installDir"
}

# Add it permanently to the user PATH.
$userPath = [Environment]::GetEnvironmentVariable(
    "Path",
    "User"
)

$userEntries = @(
    $userPath -split ";" |
    Where-Object {
        -not [string]::IsNullOrWhiteSpace($_)
    }
)

if ($userEntries -notcontains $installDir) {
    $newUserPath = ($userEntries + $installDir) -join ";"

    [Environment]::SetEnvironmentVariable(
        "Path",
        $newUserPath,
        "User"
    )
}

# Start the proxy with the correct absolute config path.
@'
@echo off
"%USERPROFILE%\CLIProxyAPI\cli-proxy-api.exe" --config "%USERPROFILE%\CLIProxyAPI\config.yaml" %*
'@ | Set-Content `
    -Path (Join-Path $installDir "cliproxy.cmd") `
    -Encoding ASCII

# Open the local Management UI.
@'
@echo off
start "" "http://127.0.0.1:8317/management.html"
'@ | Set-Content `
    -Path (Join-Path $installDir "cliproxy-ui.cmd") `
    -Encoding ASCII

# Force-stop the local proxy.
@'
@echo off
taskkill /IM cli-proxy-api.exe /F
'@ | Set-Content `
    -Path (Join-Path $installDir "cliproxy-stop.cmd") `
    -Encoding ASCII

Remove-Item `
    -Path $downloadPath `
    -Force `
    -ErrorAction SilentlyContinue

Remove-Item `
    -Path $extractDir `
    -Recurse `
    -Force `
    -ErrorAction SilentlyContinue

Write-Host ""
Write-Host "CLIProxyAPI $($release.tag_name) installed."
Write-Host "Installation: $installDir"
Write-Host "Configuration: $configPath"

if ($generatedSecrets) {
    Write-Host ""
    Write-Host "SAVE THESE IN A PASSWORD MANAGER:"
    Write-Host "Client API key: $clientKey"
    Write-Host "Management key: $managementKey"
}

Write-Host ""
Write-Host "Global commands:"
Write-Host "  cliproxy"
Write-Host "  cliproxy-ui"
Write-Host "  cliproxy-stop"
Write-Host ""
Write-Host "Open a new terminal if a command is not recognized."

Verify:

cli-proxy-api.exe --help
cliproxy --help

On an upgrade, the script preserves the existing config.yaml instead of rotating credentials without warning.

5. Understand the two passwords

CLIProxyAPI uses two different secrets.

Client API key

Configured under:

api-keys:
  - "YOUR_CLIENT_API_KEY"

Used by:

• Claude Code
• curl.exe
• Invoke-RestMethod
• Any application sending model requests

Claude Code receives it through:

ANTHROPIC_AUTH_TOKEN

Management key

Configured under:

remote-management:
  secret-key: "YOUR_MANAGEMENT_KEY"

Used by:

• The browser Management Center
• Management API requests under /v0/management

Do not use the same value for both.

Do not use placeholder text such as:

CHANGE-THIS-TO-A-STRONG-MANAGEMENT-PASSWORD

A placeholder becomes a terrible secret the moment someone decides to keep it literally.

6. Secure the local configuration

Open:

notepad "$env:USERPROFILE\CLIProxyAPI\config.yaml"

Keep the full example file, but confirm these values:

host: "127.0.0.1"
port: 8317

remote-management:
  allow-remote: false
  secret-key: "YOUR_RANDOM_MANAGEMENT_KEY"
  disable-control-panel: false
  panel-github-repository: "https://github.com/router-for-me/Cli-Proxy-API-Management-Center"

auth-dir: "~/.cli-proxy-api"

api-keys:
  - "YOUR_RANDOM_CLIENT_API_KEY"

Recommended local security values:

host: "127.0.0.1"
allow-remote: false
ws-auth: true

Why:

• 127.0.0.1 restricts the server to the current computer.
• allow-remote: false restricts management access to localhost.
• ws-auth: true keeps WebSocket endpoints authenticated.

CLIProxyAPI supports hot reload for many configuration changes, but restarting after authentication, key rotation, or provider changes is a reliable way to eliminate stale runtime state.

7. Start CLIProxyAPI from anywhere

Run:

cliproxy

Keep that terminal open while debugging.

Confirm the port:

Test-NetConnection `
    -ComputerName 127.0.0.1 `
    -Port 8317

Expected:

TcpTestSucceeded : True

Check the process:

Get-Process `
    -Name "cli-proxy-api" `
    -ErrorAction SilentlyContinue

Check which process owns port 8317:

$connection = Get-NetTCPConnection `
    -LocalPort 8317 `
    -State Listen `
    -ErrorAction SilentlyContinue

$connection

if ($connection) {
    Get-Process -Id $connection.OwningProcess
}

8. Open and understand the Management UI

Open:

cliproxy-ui

Or visit:

http://127.0.0.1:8317/management.html

Log in with:

API address:
http://127.0.0.1:8317

Password:
The value under remote-management.secret-key

The official Management Center is served from /management.html. It stores connection information in browser storage. If password remembering is enabled, treat the browser profile as trusted. Browser storage is convenience, not a hardware security module wearing a browser tab.

Dashboard

Use it to inspect:

• Server version
• Credential counts
• Active provider families
• Runtime status
• Available-model summary

Quick Start

Use it to inspect or create basic API-key and function setups.

AI Providers

Use this area for direct upstream API-key providers such as:

• Claude API keys
• Gemini API keys
• Codex API keys
• xAI API keys
• OpenAI-compatible endpoints
• Vertex-compatible endpoints

This page is not where OAuth-backed Antigravity credentials are created.

Auth Files

Use it to:

• Confirm OAuth credential files exist
• Inspect provider type
• Remove expired credentials
• Configure per-credential aliases when supported
• Configure excluded models
• Download or upload auth files

Treat downloaded auth files as passwords.

OAuth Login

Use it to initiate OAuth flows available in the installed Management Center version.

If an OAuth callback fails in the browser, use the corresponding CLI login command instead.

Quota Management

Use it to inspect:

• Credential quota status
• Cooldown state
• Provider fallback state
• Account switching behavior

Logs Viewer

Use it when:

• A request returns 401
• A model cannot be found
• An upstream credential expires
• Streaming stops unexpectedly
• Tool schemas are rejected
• A model is cooled down

Config Panel

Use it to edit:

• Client API keys
• Logging
• Retry behavior
• Proxy URL
• Routing
• Model aliases
• Excluded models
• Raw YAML

Plugins

Only enable plugins you trust. A plugin loaded into the Management Center origin may be able to access the same browser-stored management context.

9. Authenticate Codex and Antigravity

You can authenticate through the UI when the installed Management Center supports the complete flow, or use CLI commands.

Codex OAuth from PowerShell

Stop the running proxy first if the login command requires exclusive access:

cliproxy-stop

Run:

cliproxy --codex-login

If no browser opens:

cliproxy --codex-login --no-browser

After login:

cliproxy

Antigravity OAuth from PowerShell

Run:

cliproxy-stop
cliproxy --antigravity-login

If no browser opens:

cliproxy --antigravity-login --no-browser

Then restart:

cliproxy

OAuth through the UI

1. Start CLIProxyAPI.
2. Open OAuth Login.
3. Choose the provider.
4. Start the login.
5. Complete the browser flow.
6. Open Auth Files.
7. Confirm that the new credential exists.
8. Refresh the model list.
9. Restart CLIProxyAPI if the new models do not appear.

Authentication files normally live under:

%USERPROFILE%\.cli-proxy-api

Confirm Antigravity credentials exist without printing their contents:

Get-ChildItem `
    -Path "$env:USERPROFILE\.cli-proxy-api" `
    -Filter "*.json" `
    -File |
    Select-String `
        -Pattern '"type"\s*:\s*"antigravity"' `
        -List |
    Select-Object Path

10. Why AI Providers → Claude is not Antigravity

The New · Claude form under AI Providers asks for fields such as:

API key
Base URL
Proxy URL
Prefix
Request headers
Custom models
Excluded models

That form creates a direct claude-api-key provider entry.

It is appropriate when you have:

• An Anthropic API key
• A compatible Claude endpoint
• A custom upstream Base URL

It is not required for Antigravity OAuth.

For Antigravity:

OAuth Login
    ↓
Antigravity credential
    ↓
Auth Files
    ↓
Claude and Gemini models appear in /v1/models

Therefore:

AI Providers → Claude:
Leave empty for an OAuth-only Antigravity setup.

OAuth Login:
Use for Antigravity authentication.

Auth Files:
Confirm the OAuth credential.

Available Models:
Confirm Claude and Gemini model IDs.

Do not paste the CLIProxyAPI client key into the New · Claude API-key field. That would make the gateway attempt to use its own downstream key as an upstream provider credential.

11. List and verify available models

PowerShell with a direct key assignment

$proxyKey = "YOUR_CLIENT_API_KEY"

$models = Invoke-RestMethod `
    -Uri "http://127.0.0.1:8317/v1/models" `
    -Headers @{
        Authorization = "Bearer $proxyKey"
    }

$models.data |
    Sort-Object id |
    Format-Table id, owned_by -AutoSize

PowerShell with a secure prompt

$proxyKey = Read-Host `
    "Paste your CLIProxyAPI client API key"

At the prompt, paste the key and press Enter.

Then:

$models = Invoke-RestMethod `
    -Uri "http://127.0.0.1:8317/v1/models" `
    -Headers @{
        Authorization = "Bearer $proxyKey"
    }

Important Read-Host mistake

This is wrong:

$proxyKey = Read-Host "cc-local-your-real-key"

The quoted text is only the prompt label. If you press Enter without typing anything afterward, $proxyKey becomes empty.

This is correct:

$proxyKey = Read-Host "Paste your client API key"

Then paste the key when PowerShell displays the prompt.

Or assign it directly:

$proxyKey = "YOUR_CLIENT_API_KEY"

Filter Antigravity models

$models.data |
    Where-Object {
        $_.id -match "claude|gemini"
    } |
    Sort-Object id |
    Format-Table id, owned_by -AutoSize

Filter GPT models

$models.data |
    Where-Object {
        $_.id -match "^gpt-|codex"
    } |
    Sort-Object id |
    Format-Table id, owned_by -AutoSize

Example model catalogue observed in one setup

The exact catalogue changes. In one July 2026 setup, CLIProxyAPI exposed:

GPT:
gpt-5.4-mini
gpt-5.4
gpt-5.5
gpt-5.6-terra
gpt-5.6-luna

Claude:
claude-opus-4-6-thinking
claude-sonnet-4-6

Gemini:
gemini-3.5-flash-low
gemini-3.5-flash-extra-low

Use the IDs returned by your own server. Tutorials age. Model catalogues age faster and with considerably more branding.

12. Understand thinking suffixes

CLIProxyAPI accepts thinking or reasoning instructions in parentheses after a model name.

Examples:

claude-opus-4-6-thinking(high)
gemini-3.5-flash-low(high)
gpt-5.5(high)

Supported level presets include:

Examples:

claude-opus-4-6-thinking(high)

CLIProxyAPI normalizes the model name and applies a Claude thinking budget.

gemini-3.5-flash-low(high)

CLIProxyAPI routes to gemini-3.5-flash-low and requests a high Gemini thinking budget.

The suffixed version may not appear in /v1/models. It is a per-request routing instruction, not necessarily a separately advertised model.

Unsupported settings may be:

• Dropped
• Clamped to the supported range
• Rejected with HTTP 400

Always test the exact suffixed model before saving it in Claude Code.

13. Test models before configuring Claude Code

Load the key:

$proxyKey = Read-Host `
    "Paste your CLIProxyAPI client API key"

Create the test function:

function Test-CLIProxyModel {
    param(
        [Parameter(Mandatory)]
        [string]$Model
    )

    Write-Host ""
    Write-Host "Testing: $Model"

    $headers = @{
        Authorization       = "Bearer $proxyKey"
        "anthropic-version" = "2023-06-01"
        "content-type"      = "application/json"
    }

    $body = @{
        model      = $Model
        max_tokens = 1000

        messages = @(
            @{
                role    = "user"
                content = "Reply with exactly: MODEL WORKING"
            }
        )
    } |
        ConvertTo-Json -Depth 10

    try {
        $response = Invoke-RestMethod `
            -Uri "http://127.0.0.1:8317/v1/messages" `
            -Method Post `
            -Headers $headers `
            -Body $body

        $response.content |
            Where-Object {
                $_.text
            } |
            ForEach-Object {
                $_.text
            }

        Write-Host "SUCCESS: $Model"
    }
    catch {
        Write-Host "FAILED: $Model"
        Write-Host $_.Exception.Message

        if ($_.ErrorDetails.Message) {
            Write-Host $_.ErrorDetails.Message
        }
    }
}

Test the GPT mapping

Test-CLIProxyModel "gpt-5.6-terra"
Test-CLIProxyModel "gpt-5.5"
Test-CLIProxyModel "gpt-5.4-mini"

Test the Antigravity mapping

Test-CLIProxyModel `
    "claude-opus-4-6-thinking(high)"

Test-CLIProxyModel `
    "claude-sonnet-4-6"

Test-CLIProxyModel `
    "gemini-3.5-flash-low(high)"

Expected:

MODEL WORKING
SUCCESS: claude-opus-4-6-thinking(high)

MODEL WORKING
SUCCESS: claude-sonnet-4-6

MODEL WORKING
SUCCESS: gemini-3.5-flash-low(high)

Do not create the permanent profile until all selected models succeed.

14. Create a reusable GPT profile

Create:

%USERPROFILE%\.claude-gpt\settings.json

Run:

$profileDir = "$env:USERPROFILE\.claude-gpt"
$settingsPath = Join-Path $profileDir "settings.json"

New-Item `
    -ItemType Directory `
    -Path $profileDir `
    -Force |
    Out-Null

$proxyKey = Read-Host `
    "Paste your CLIProxyAPI client API key"

$settings = [ordered]@{
    model = "opus"

    env = [ordered]@{
        ANTHROPIC_BASE_URL =
            "http://127.0.0.1:8317"

        ANTHROPIC_AUTH_TOKEN =
            $proxyKey

        ANTHROPIC_DEFAULT_OPUS_MODEL =
            "gpt-5.6-terra"

        ANTHROPIC_DEFAULT_SONNET_MODEL =
            "gpt-5.5"

        ANTHROPIC_DEFAULT_HAIKU_MODEL =
            "gpt-5.4-mini"
    }
}

$settings |
    ConvertTo-Json -Depth 20 |
    Set-Content `
        -Path $settingsPath `
        -Encoding UTF8

Write-Host "Created GPT profile:"
Write-Host $settingsPath

The mapping is:

opus   → gpt-5.6-terra
sonnet → gpt-5.5
haiku  → gpt-5.4-mini

The top-level setting:

"model": "opus"

makes opus the permanent default unless overridden by:

• /model
• claude --model ...
• ANTHROPIC_MODEL

Claude Code model selection precedence is:

/model during the session
    ↓
--model at startup
    ↓
ANTHROPIC_MODEL
    ↓
"model" in settings.json

15. Create a reusable Antigravity profile

Create:

%USERPROFILE%\.claude-antigravity\settings.json

Run:

$profileDir = "$env:USERPROFILE\.claude-antigravity"
$settingsPath = Join-Path $profileDir "settings.json"

New-Item `
    -ItemType Directory `
    -Path $profileDir `
    -Force |
    Out-Null

$proxyKey = Read-Host `
    "Paste your CLIProxyAPI client API key"

$settings = [ordered]@{
    model = "opus"

    env = [ordered]@{
        ANTHROPIC_BASE_URL =
            "http://127.0.0.1:8317"

        ANTHROPIC_AUTH_TOKEN =
            $proxyKey

        ANTHROPIC_DEFAULT_OPUS_MODEL =
            "claude-opus-4-6-thinking(high)"

        ANTHROPIC_DEFAULT_SONNET_MODEL =
            "claude-sonnet-4-6"

        ANTHROPIC_DEFAULT_HAIKU_MODEL =
            "gemini-3.5-flash-low(high)"
    }
}

$settings |
    ConvertTo-Json -Depth 20 |
    Set-Content `
        -Path $settingsPath `
        -Encoding UTF8

Write-Host "Created Antigravity profile:"
Write-Host $settingsPath

The mapping is:

opus
→ claude-opus-4-6-thinking(high)

sonnet
→ claude-sonnet-4-6

haiku
→ gemini-3.5-flash-low(high)

Recommended uses:

Inspect the profile without displaying unrelated secrets elsewhere:

Get-Content `
    "$env:USERPROFILE\.claude-antigravity\settings.json"

Do not commit profile settings containing ANTHROPIC_AUTH_TOKEN.

16. Create launchers for PowerShell and CMD

A clean launcher design should avoid giving a .ps1 and .cmd file the same basename.

Why:

• PowerShell may resolve the .ps1.
• Command Prompt resolves the .cmd.
• Get-Command and where.exe then appear to disagree.
• Both are technically correct, which is the least useful kind of correct.

Use internal scripts named:

invoke-claude-gpt.ps1
invoke-claude-antigravity.ps1

Expose public commands named:

claude-gpt.cmd
claude-antigravity.cmd

This gives both PowerShell and CMD one consistent public command.

Shared launcher behavior

Each launcher:

1. Checks whether port 8317 is listening.
2. Starts CLIProxyAPI when necessary.
3. Waits until the proxy is ready.
4. Sets CLAUDE_CONFIG_DIR.
5. Launches Claude Code with opus.
6. Passes through extra Claude Code arguments.

Create the GPT launcher

$launcherDir = "$env:USERPROFILE\CLIProxyAPI"
$scriptPath = Join-Path `
    $launcherDir `
    "invoke-claude-gpt.ps1"

@'
$ErrorActionPreference = "Stop"

$proxyExe = "$env:USERPROFILE\CLIProxyAPI\cli-proxy-api.exe"
$configPath = "$env:USERPROFILE\CLIProxyAPI\config.yaml"
$profileDir = "$env:USERPROFILE\.claude-gpt"

function Wait-ForCLIProxy {
    param(
        [int]$Port = 8317,
        [int]$Attempts = 40,
        [int]$DelayMilliseconds = 250
    )

    for ($attempt = 0; $attempt -lt $Attempts; $attempt++) {
        $listener = Get-NetTCPConnection `
            -LocalPort $Port `
            -State Listen `
            -ErrorAction SilentlyContinue

        if ($listener) {
            return $true
        }

        Start-Sleep -Milliseconds $DelayMilliseconds
    }

    return $false
}

$listener = Get-NetTCPConnection `
    -LocalPort 8317 `
    -State Listen `
    -ErrorAction SilentlyContinue

if (-not $listener) {
    Write-Host "Starting CLIProxyAPI..."

    Start-Process `
        -FilePath $proxyExe `
        -ArgumentList @(
            "--config",
            "`"$configPath`""
        ) `
        -WorkingDirectory (Split-Path $proxyExe) `
        -WindowStyle Hidden

    if (-not (Wait-ForCLIProxy)) {
        throw "CLIProxyAPI did not start on port 8317."
    }
}

$env:CLAUDE_CONFIG_DIR = $profileDir

Write-Host "Claude profile: GPT"
Write-Host "Starting alias: opus"
Write-Host ""

& claude --model opus @args
'@ | Set-Content `
    -Path $scriptPath `
    -Encoding UTF8

Create the CMD wrapper:

@'
@echo off
powershell.exe -NoLogo -NoProfile -ExecutionPolicy Bypass -File "%USERPROFILE%\CLIProxyAPI\invoke-claude-gpt.ps1" %*
exit /b %ERRORLEVEL%
'@ | Set-Content `
    -Path "$env:USERPROFILE\CLIProxyAPI\claude-gpt.cmd" `
    -Encoding ASCII

Create the Antigravity launcher

$launcherDir = "$env:USERPROFILE\CLIProxyAPI"
$scriptPath = Join-Path `
    $launcherDir `
    "invoke-claude-antigravity.ps1"

@'
$ErrorActionPreference = "Stop"

$proxyExe = "$env:USERPROFILE\CLIProxyAPI\cli-proxy-api.exe"
$configPath = "$env:USERPROFILE\CLIProxyAPI\config.yaml"
$profileDir = "$env:USERPROFILE\.claude-antigravity"

function Wait-ForCLIProxy {
    param(
        [int]$Port = 8317,
        [int]$Attempts = 40,
        [int]$DelayMilliseconds = 250
    )

    for ($attempt = 0; $attempt -lt $Attempts; $attempt++) {
        $listener = Get-NetTCPConnection `
            -LocalPort $Port `
            -State Listen `
            -ErrorAction SilentlyContinue

        if ($listener) {
            return $true
        }

        Start-Sleep -Milliseconds $DelayMilliseconds
    }

    return $false
}

$listener = Get-NetTCPConnection `
    -LocalPort 8317 `
    -State Listen `
    -ErrorAction SilentlyContinue

if (-not $listener) {
    Write-Host "Starting CLIProxyAPI..."

    Start-Process `
        -FilePath $proxyExe `
        -ArgumentList @(
            "--config",
            "`"$configPath`""
        ) `
        -WorkingDirectory (Split-Path $proxyExe) `
        -WindowStyle Hidden

    if (-not (Wait-ForCLIProxy)) {
        throw "CLIProxyAPI did not start on port 8317."
    }
}

$env:CLAUDE_CONFIG_DIR = $profileDir

Write-Host "Claude profile: Antigravity"
Write-Host "Starting alias: opus"
Write-Host ""

& claude --model opus @args
'@ | Set-Content `
    -Path $scriptPath `
    -Encoding UTF8

Create its CMD wrapper:

@'
@echo off
powershell.exe -NoLogo -NoProfile -ExecutionPolicy Bypass -File "%USERPROFILE%\CLIProxyAPI\invoke-claude-antigravity.ps1" %*
exit /b %ERRORLEVEL%
'@ | Set-Content `
    -Path "$env:USERPROFILE\CLIProxyAPI\claude-antigravity.cmd" `
    -Encoding ASCII

Migrate an existing same-name launcher

If you already created:

claude-antigravity.ps1
claude-antigravity.cmd

remove the ambiguity:

$launcherDir = "$env:USERPROFILE\CLIProxyAPI"

if (Test-Path "$launcherDir\claude-antigravity.ps1") {
    Move-Item `
        -Path "$launcherDir\claude-antigravity.ps1" `
        -Destination "$launcherDir\invoke-claude-antigravity.ps1" `
        -Force
}

Then recreate claude-antigravity.cmd so it points to:

invoke-claude-antigravity.ps1

Add the launcher folder to PATH

Current terminal:

$launcherDir = "$env:USERPROFILE\CLIProxyAPI"

if (($env:Path -split ";") -notcontains $launcherDir) {
    $env:Path += ";$launcherDir"
}

Permanent user PATH:

$launcherDir = "$env:USERPROFILE\CLIProxyAPI"

$userPath = [Environment]::GetEnvironmentVariable(
    "Path",
    "User"
)

$userEntries = @(
    $userPath -split ";" |
    Where-Object {
        -not [string]::IsNullOrWhiteSpace($_)
    }
)

if ($userEntries -notcontains $launcherDir) {
    [Environment]::SetEnvironmentVariable(
        "Path",
        ($userEntries + $launcherDir) -join ";",
        "User"
    )
}

Open a new terminal after a permanent PATH change.

Verify in PowerShell

Get-Command claude-gpt
Get-Command claude-antigravity

Expected source:

C:\Users\<YOU>\CLIProxyAPI\claude-gpt.cmd
C:\Users\<YOU>\CLIProxyAPI\claude-antigravity.cmd

Verify in Command Prompt

where claude-gpt
where claude-antigravity

Expected:

C:\Users\<YOU>\CLIProxyAPI\claude-gpt.cmd
C:\Users\<YOU>\CLIProxyAPI\claude-antigravity.cmd

17. Use the commands from any project

PowerShell

cd "D:\projects\my-app"
claude-gpt

Or:

cd "D:\projects\my-app"
claude-antigravity

Command Prompt

Use /d when changing drives:

cd /d D:\projects\my-app
claude-gpt

Or:

cd /d D:\projects\my-app
claude-antigravity

Pass Claude Code arguments

claude-antigravity --model sonnet

claude-antigravity --model haiku

claude-gpt --model sonnet

The launcher normally uses:

--model opus

That startup flag ensures a new launch starts on the configured opus mapping.

18. Switch models inside Claude Code

Open the picker:

/model

Switch to the main model:

/model opus

Switch to the normal model:

/model sonnet

Switch to the fast model:

/model haiku

Check status:

/status

GPT profile mapping

opus   → gpt-5.6-terra
sonnet → gpt-5.5
haiku  → gpt-5.4-mini

Antigravity profile mapping

opus   → claude-opus-4-6-thinking(high)
sonnet → claude-sonnet-4-6
haiku  → gemini-3.5-flash-low(high)

A model selected with /model applies immediately during the session.

The next invocation of:

claude-antigravity

starts with opus again because the launcher passes:

claude --model opus

19. Optional automatic startup

The profile launchers already start CLIProxyAPI when port 8317 is not listening. That is sufficient for most users.

To start CLIProxyAPI automatically at Windows login, create a Scheduled Task.

$taskName = "CLIProxyAPI"
$exe = "$env:USERPROFILE\CLIProxyAPI\cli-proxy-api.exe"
$config = "$env:USERPROFILE\CLIProxyAPI\config.yaml"
$workingDirectory = "$env:USERPROFILE\CLIProxyAPI"

$action = New-ScheduledTaskAction `
    -Execute $exe `
    -ArgumentList "--config `"$config`"" `
    -WorkingDirectory $workingDirectory

$trigger = New-ScheduledTaskTrigger `
    -AtLogOn

$principal = New-ScheduledTaskPrincipal `
    -UserId "$env:USERDOMAIN\$env:USERNAME" `
    -LogonType Interactive `
    -RunLevel Limited

Register-ScheduledTask `
    -TaskName $taskName `
    -Action $action `
    -Trigger $trigger `
    -Principal $principal `
    -Description "Start CLIProxyAPI at user logon." `
    -Force

Start it now:

Start-ScheduledTask `
    -TaskName "CLIProxyAPI"

Inspect:

Get-ScheduledTask `
    -TaskName "CLIProxyAPI"

Stop:

Stop-ScheduledTask `
    -TaskName "CLIProxyAPI"

Remove:

Unregister-ScheduledTask `
    -TaskName "CLIProxyAPI" `
    -Confirm:$false

Do not combine multiple automatic-start methods unless you enjoy debugging duplicate processes and occupied ports.

20. Daily operating routine

Simplest GPT workflow

cd "D:\projects\my-app"
claude-gpt

Simplest Antigravity workflow

cd "D:\projects\my-app"
claude-antigravity

Open the UI

cliproxy-ui

Manual debugging workflow

Terminal 1:

cliproxy

Terminal 2:

$env:CLAUDE_CONFIG_DIR =
    "$env:USERPROFILE\.claude-antigravity"

claude --model opus

The visible proxy terminal is better for troubleshooting because you can watch credential loading, routing, and upstream errors.

21. Stop, update, and back up the setup

Exit Claude Code

/exit

Stop CLIProxyAPI

If it is running in a visible terminal:

Ctrl+C

From any terminal:

cliproxy-stop

PowerShell alternative:

Stop-Process `
    -Name "cli-proxy-api" `
    -Force `
    -ErrorAction SilentlyContinue

Back up configuration

Copy-Item `
    "$env:USERPROFILE\CLIProxyAPI\config.yaml" `
    "$env:USERPROFILE\CLIProxyAPI\config.backup.yaml" `
    -Force

Back up OAuth credentials

Copy-Item `
    "$env:USERPROFILE\.cli-proxy-api" `
    "$env:USERPROFILE\.cli-proxy-api-backup" `
    -Recurse `
    -Force

Back up Claude profiles

Copy-Item `
    "$env:USERPROFILE\.claude-gpt" `
    "$env:USERPROFILE\.claude-gpt-backup" `
    -Recurse `
    -Force

Copy-Item `
    "$env:USERPROFILE\.claude-antigravity" `
    "$env:USERPROFILE\.claude-antigravity-backup" `
    -Recurse `
    -Force

Update CLIProxyAPI

1. Stop CLIProxyAPI.
2. Create backups.
3. Run the installation script again.
4. Confirm config.yaml was preserved.
5. Start CLIProxyAPI.
6. Refresh /v1/models.
7. Test the selected model mappings.
8. Launch both Claude profiles.

22. Troubleshooting

22.1 401 Invalid API key

Symptoms:

The remote server returned an error: (401) Unauthorized.
{"error":"Invalid API key"}

First test /v1/models:

$proxyKey = Read-Host `
    "Paste your CLIProxyAPI client API key"

Invoke-RestMethod `
    -Uri "http://127.0.0.1:8317/v1/models" `
    -Headers @{
        Authorization = "Bearer $proxyKey"
    }

Common causes:

• $proxyKey is empty.
• The wrong key was used.
• The management password was used instead of the client key.
• config.yaml changed but the running process is stale.
• The key in Claude Code settings does not match api-keys.

Inspect whether the variable is empty without printing it:

if ([string]::IsNullOrWhiteSpace($proxyKey)) {
    Write-Host "The key is empty."
}
else {
    Write-Host "Key loaded. Length: $($proxyKey.Length)"
}

Load the key from a profile:

$profile = Get-Content `
    "$env:USERPROFILE\.claude-antigravity\settings.json" `
    -Raw |
    ConvertFrom-Json

$proxyKey = $profile.env.ANTHROPIC_AUTH_TOKEN

22.2 The key itself was entered as a command

This produces:

The term 'cc-local-...' is not recognized

A key is data, not a command.

Correct:

$proxyKey = "YOUR_CLIENT_API_KEY"

Or:

$proxyKey = Read-Host "Paste your client API key"

22.3 Only GPT models appear after Antigravity login

Symptoms:

/v1/models shows GPT models
Claude and Gemini models are missing

Restart the proxy visibly:

cliproxy-stop
cliproxy

Then refresh:

$models = Invoke-RestMethod `
    -Uri "http://127.0.0.1:8317/v1/models" `
    -Headers @{
        Authorization = "Bearer $proxyKey"
    }

$models.data |
    Where-Object {
        $_.id -match "claude|gemini"
    } |
    Format-Table id, owned_by

Confirm the Antigravity auth file exists.

If necessary, repeat:

cliproxy-stop
cliproxy --antigravity-login
cliproxy

22.4 claude-antigravity is not recognized

Check the files:

Get-ChildItem `
    "$env:USERPROFILE\CLIProxyAPI\*claude*"

Check PATH:

$env:Path -split ";" |
    Where-Object {
        $_ -match "CLIProxyAPI"
    }

Add it to the current terminal:

$env:Path += ";$env:USERPROFILE\CLIProxyAPI"

Open a new terminal after permanent PATH changes.

Verify:

Get-Command claude-antigravity

CMD:

where claude-antigravity

22.5 PowerShell finds .ps1, CMD finds .cmd

This happens when both files have the same basename:

claude-antigravity.ps1
claude-antigravity.cmd

PowerShell may resolve the .ps1, while CMD resolves the .cmd.

Use:

invoke-claude-antigravity.ps1
claude-antigravity.cmd

Then both shells use the public .cmd command consistently.

22.6 Management UI returns 404

Confirm:

remote-management:
  secret-key: "NOT_EMPTY"
  disable-control-panel: false

Restart:

cliproxy-stop
cliproxy

Open:

http://127.0.0.1:8317/management.html

22.7 Management UI rejects the password

Use the management key:

remote-management:
  secret-key:

Do not use:

api-keys:

If the server hashes or transforms the stored management value internally, continue using the original plaintext password that you generated.

22.8 Model not found

Refresh /v1/models and copy the exact ID.

$models.data |
    Sort-Object id |
    Select-Object id, owned_by

If using a suffix:

gemini-3.5-flash-low(high)

verify that the base model exists:

gemini-3.5-flash-low

22.9 Gemini high thinking fails

Replace:

gemini-3.5-flash-low(high)

with:

gemini-3.5-flash-low

The provider may reject or clamp unsupported thinking levels.

22.10 Claude Code starts on the wrong model

Inspect:

Get-Content `
    "$env:USERPROFILE\.claude-antigravity\settings.json"

Confirm:

"model": "opus"

Confirm:

"ANTHROPIC_DEFAULT_OPUS_MODEL":
"claude-opus-4-6-thinking(high)"

Check whether the launcher contains:

claude --model opus

Inside Claude Code:

/status
/model

Remember the precedence:

/model
--model
ANTHROPIC_MODEL
settings.json model

22.11 Port 8317 is occupied

$connection = Get-NetTCPConnection `
    -LocalPort 8317 `
    -ErrorAction SilentlyContinue

$connection

if ($connection) {
    Get-Process -Id $connection.OwningProcess
}

Stop the duplicate process before starting another one.

22.12 Hidden launcher starts the wrong config

The launcher must pass the absolute path:

--config "$env:USERPROFILE\CLIProxyAPI\config.yaml"

Do not rely on the current working directory.

22.13 Tool calls fail only on Antigravity

A model can answer simple text requests while rejecting a tool schema or streaming payload.

Use the Logs Viewer and reproduce with:

• A simple text prompt
• A file-reading request
• A Bash tool request
• An MCP request

This distinguishes model availability from full Claude Code protocol compatibility.

23. Security checklist

• Bind CLIProxyAPI to 127.0.0.1.
• Keep remote management disabled.
• Keep WebSocket authentication enabled.
• Use separate random client and management keys.
• Never publish config.yaml.
• Never publish Claude profile settings.json files containing tokens.
• Never publish .cli-proxy-api.
• Never include real keys in a blog screenshot.
• Rotate keys exposed in chat, terminal recordings, issue reports, or repositories.
• Do not paste the client key into an upstream provider form.
• Do not reuse placeholder passwords.
• Review plugins before enabling them.
• Back up OAuth credentials securely.
• Test both model output and tool calling after upgrades.
• Treat this as an unofficial compatibility workflow.

Rotate the client API key

1. Open Config Panel.
2. Replace the entry under api-keys.
3. Save.
4. Restart CLIProxyAPI.
5. Update:
   • .claude-gpt\settings.json
   • .claude-antigravity\settings.json
6. Test /v1/models.
7. Test all selected models.

24. Command reference

Start the proxy

cliproxy

Open the UI

cliproxy-ui

Stop the proxy

cliproxy-stop

Codex login

cliproxy --codex-login

Antigravity login

cliproxy --antigravity-login

List models

curl.exe "http://127.0.0.1:8317/v1/models" `
  -H "Authorization: Bearer YOUR_CLIENT_API_KEY"

Start the GPT profile

claude-gpt

Start the Antigravity profile

claude-antigravity

CMD from another drive

cd /d D:\projects\my-app
claude-antigravity

Switch models

/model opus
/model sonnet
/model haiku

Inspect status

/status
/model

Test a model

Test-CLIProxyModel `
    "claude-opus-4-6-thinking(high)"

Final result

The completed workflow is:

Open a terminal in any project
    ↓
claude-gpt
or
claude-antigravity
    ↓
The launcher starts CLIProxyAPI if necessary
    ↓
CLAUDE_CONFIG_DIR selects the correct profile
    ↓
Claude Code starts with opus
    ↓
opus maps to the chosen upstream model

For GPT:

opus   → gpt-5.6-terra
sonnet → gpt-5.5
haiku  → gpt-5.4-mini

For Antigravity:

opus   → claude-opus-4-6-thinking(high)
sonnet → claude-sonnet-4-6
haiku  → gemini-3.5-flash-low(high)

The Management UI controls the gateway:

OAuth accounts
Auth files
Client API keys
Provider configuration
Model discovery
Aliases
Excluded models
Logs
Quota and cooldown state

Claude Code profiles control the client:

Gateway URL
Client bearer token
Alias-to-model mapping
Default model
Per-session switching
Session history and plugins

Once configured, the daily experience is one command. Reaching that one command merely required OAuth, two passwords, a local gateway, model translation, separate profiles, Windows PATH, PowerShell, CMD wrappers, and a small amount of ceremony. Software continues to define convenience with impressive confidence.

Official references

• CLIProxyAPI repository
• CLIProxyAPI documentation
• CLIProxyAPI basic configuration
• CLIProxyAPI thinking suffixes
• CLIProxyAPI Management Center
• Claude Code environment variables
• Claude Code model configuration
• Claude Code settings
• Claude Code configuration directory
